SatHero Meters
Get your transponder parameters to go!
Just scan this QR with your smart phone and bookmark it so you can
return later!
North and South America
Satellites from 61.5W to 177.0W
Satellites from 1.8E to 70.5E
April 28, 2012 - Today we released our latest Update Tool for the SH-200. Registered users can find it on our software page. If you are a registered user and don't have access to our software page you can request your username and password here.
This release solves the continuous loop problem experienced when using some USB to RS-232 converter cables.
UpdateTools_20120428 Change Log
===============================
***Fixed the continuous loop loading problem experienced when using
some USB to RS232 converter cables
***Improved stability
***Improved error checking
***Improved loading speed
***Minor bug fixes
Monday November 28, 2011 the latest SH-200 software is released. This version adds speed, improved signal locking and improved accuracy. Besides software improvements, it now gives you the ability to adjust the brightness of the LCD. You can see the LCD instructions here. Registered owners can download the new software from our software page.
Access to our password protected software area which contains the latest software releases, satellite lists, and proprietary lists.
World wide satellite/transponder list in easy to understand
format. The list is formatted the same way the meter is.
List is updated monthly. Registered owners can request a
fresh list at any time.
1. Simplified design, simplified menus, easy operations. The whole meter has only seven shortcut buttons, easy for new users.
2. High quality and stability from our tuner imported from Japan to ensure display data accuracy.
3. Easily and quickly search DVB-S2, DVB-S, MPEG-4, ABS-S, MPEG-4, CBS2/MPEG4, ISDB(Japan BSD HDTV) and other satellite signals.
4. High contrast, anti-glare LCD Screen in bold font. Menu can be read easily in the sun without shading.
5. With background lights use at night or in dark environments.
6. Use our specialized software tools to download and update the latest satellite parameters from our website. New databases can be easily imported into the instrument.
7. Software tools are compatible with Microsoft Office Excel. Users can easily add, edit or delete the names of satellites, locations and channel parameters.
8. Users can modify the satellite parameters using the shortcut buttons.
9. When the dish is close to the required satellite, a number of LED lamps and dBuV values will synchronously display signal quality. Lock light and tone will alert user.
10. When satellite signal is locked the meter can search and display all programs name of the transponder.
11. (Cable Test) ports: to help users detect faulty cables.
12. Small and light weight, the whole device including lithium battery weighs only 0.28kg.
13.Designed with removable rear cover, for easy battery replacement.
14. Hand held with wrist strap.
15. When fully charged, the powerful lithium battery can continuously work for up to 3.5 hours with standby time up to 5 hours or more.
- Smallest and fastest digital signal meter
- Support DVB-S，DVB-S2, MPEG-4, ABS-S, CBS MPEG-4, ISDB protocol
- Tests the cable
- Input Frequency 950～2150MHz
- Input Level -65～ -25dBm
- Input Impedance 75Ω
- Shows quality readings by LED
- Shows power and NIT value
- Preset global satellite data
- Programmable parameter
- Signal Lock audio tone
- Scan and show the channel numbers
- Clear and easy to read LCD
- All operations are on one screen
- LCD automatic turn off
- 22KHz switches automatically
- Function operation and Signal Lock Light
- Indicator Lights for 13/18 volts
- Indicator lights for 22 KHz
- LNB short-circuit protection
- USB port for software upgrades
- Global AC power charger included
- Hand strap included
- USB software upgrade cable included
- Removable battery design
- High-capacity lithium battery
